ZkJ-3
Available on request
GTJ Test
ZkJ-3 Vacuum Mixer
The vacuum mixer is a small mixer with a vacuum device installed. It is an important device for mixing sealants, structural adhesives,…
Product imagery
GTJ Test
ZC3-A Concrete Rebound Hammer Black
ZC3-A concrete test hammer is applied to test the compressive strength of building concrete components, bridge and so on. Standard: JGJ/T23-2011; GB /T9138-1988; JJG817-93; ASTM C 805; BS 1881:202; NF P18-417; DIN 1048; UNI 9189 1) Center rod is made from imported material, high accuracy and durable resistance
PriceRequest price
Available on request
Final specifications, commercial terms, lead time, and documentation are confirmed against your application.
ZC3-A concrete test hammer is applied to test the compressive strength of building concrete components, bridge and so on. Standard: JGJ/T23-2011; GB /T9138-1988; JJG817-93; ASTM C 805; BS 1881:202; NF P18-417; DIN 1048; UNI 9189 1) Center rod is made from imported material, high accuracy and durable resistance
Product route
- Category
- Concrete Testing Equipment
- Manufacturer
- GTJ Test
- Industries
- Construction & Infrastructure, Laboratories & Quality Control
Standard Impact Energy2.207±0.1J (0.225Kgf.m)
The static friction of pointer slider0.65N±0.15N
Length of spring stretch75±0.3mm
The average rebound values on steel anvil80±2
Measuring Range10~60Mpa
ItemConcrete Schmidt Hammer
The static friction of the pointer slider0.65N±0.15N
The radius of spherical tip25mm±1mm
Working Temperature-10℃~+50℃
Working Humidity≤90%RH
Weight with package2.2
Product-specific documentationProvided with the selected technical configuration
Sibtain Pakistan company profileOfficial PDF
Manufacturer informationExternal website
