Observation angle of the instrument1.05 degrees
Incident angle is beta88.76 degrees
Complementary angle1.24 degrees
Light Source Color Temperature2856K+50K (CIEA Light Source)
The detectorsilicon diode + V (lambda) rectifier, meets the requirements of CIE standard spectrophotometric observer spectral optical efficiency V (lambda)
The measurement range of L retroreflectiveCoefficient R'is 0-3000 MCD lx-1 m-2
Battery Continuous Working Time72 Hours
Data Storage10,000 Test Information
Screen4.5 "854×480
Computer ConnectionTF Storage Card
Charging220VAC 50HZ; DC8.4V
Power supplylithium (6600 mah)
Protection LevelIP54
Working temperature– 15 C ~ + 50 C
Operating humidit10-90%, no condensation
Volume (length x width x height)450mm x 132 mm x 132 mm
Net weight5kg
The measurement range of L retroreflectiveCoefficient R’is 0-3000 MCD lx-1 m-2
Screen4.5 “854×480
