W202
Available on request
GTJ Test
W202 Wireless concrete crack width gauge
F230 Wireless concrete crack width gauge is used to measure crack width in concrete buildings such as houses, roads, and bridges.
Product imagery
GTJ Test
GTJ-Pull-out Anchor Tester
China leading construction material testing equipment manufacturer. We will contact you within 1 working day, please pay attention to the email with the suffix “@gtj-test.com”.
PriceRequest price
Available on request
Final specifications, commercial terms, lead time, and documentation are confirmed against your application.
China leading construction material testing equipment manufacturer. We will contact you within 1 working day, please pay attention to the email with the suffix “@gtj-test.com”.
Product route
- Category
- Non-Destructive Testing Equipment
- Manufacturer
- GTJ Test
- Industries
- Construction & Infrastructure, Laboratories & Quality Control
Product numberGTJ-10 · GTJ-20 · GTJ-30 · GTJ-50 · GTJ-100
Center hole of cylinder27mm · 35mm · 45mm · 60mm · 90mm
Cylinder stroke60mm · 80mm · 80mm · 120mm · 150mm
Measuring range0-100kN · 0-200kN · 0-300kN · 0-500kN · 0-1000kN
Cylinder weight5.5kg · 13kg · 15kg · 25kg · 28kg
Common anchorsΦ6-20 · Φ6-25 · Φ6-32 · Φ6-32 · Φ25-40
Tie rodM18 · M22 · M24 · M30 · M40
Conversion headM6-20 · M6-24 · M6-27 · M6-27 · M6-33
Resolution0.01kN · 0.01kN · 0.01kN · 0.01kN · 0.01kN
Product-specific documentationProvided with the selected technical configuration
Sibtain Pakistan company profileOfficial PDF
Manufacturer informationExternal website
