GTJ Test
4114 Non-nuclear Soil Density Gauge
The 4114 Non-nuclear soil density gauge (EDG) accurately measures soil density, moisture content and compaction in roads and foundations. The measurement accuracy depends mainly on the correct use of the operator, so a detailed reading of this operating manual will be available. Help you to use the product better. Waterproof connection, but it is best not to use it in rainy days According to the typical compacted soil dry density accuracy: within 3% of the standard physical test
PriceRequest price
Available on request
Final specifications, commercial terms, lead time, and documentation are confirmed against your application.
The 4114 Non-nuclear soil density gauge (EDG) accurately measures soil density, moisture content and compaction in roads and foundations. The measurement accuracy depends mainly on the correct use of the operator, so a detailed reading of this operating manual will be available. Help you to use the product better. Waterproof connection, but it is best not to use it in rainy days According to the typical compacted soil dry density accuracy: within 3% of the standard physical test
Product route
- Category
- Soil Testing Equipment
- Manufacturer
- GTJ Test
- Industries
- Construction & Infrastructure, Laboratories & Quality Control, Roads & Highways
EDG host and connectorWaterproof connection, but it is best not to use it in rainy days
Wet density rangeAccording to the typical compacted soil dry density accuracy: within 3% of the standard physical test
Moisture content rangeAccording to the accuracy of typical compacted soil moisture content: within 3% of the standard physical test
Maximum RS -232 cable length100cm
Internal power supply12V nickel-hydrogen, 2000mAh capacity
Battery lifeAbout 24 hours
Operating temperature range0 to 50℃
Humidity range5% to 90%
Product nameColor Screen Non-nuclear gauge
Display7.0 inch display
Battery3.7V 、13200mAh Lithium-ion rechargeable battery
Electromagnetic frequency40~100K,Low frequency radiationless
Wet density rangeStandard compacted soil field range
Dry density accuracyWithin 1.5% of standard
Humidity rangeStandard compacted soil field range
Humidity accuracyWithin 1.5% of standard tests
Environment temperature-20 °C～50 °C
Temperature compensationyes
Storage capacity100000 Engineering test sites,48 soil models
Ambient humidity5～90%
Measuring Depth150-400mm
InteractionTouch Screen
GPSOptional configuration加1000
wireless data transmissionOptional configuration
Report export methodOne-click report generation, USB copy To PC
Special FunctionsAutomatic clock timing (GPS required)
Battery life>10h(in case of low backlight)
Charge modeUSB 5V recharge
Main engine size236mm×135mm×40mm
Net weight1.3kg
Product-specific documentationProvided with the selected technical configuration
